Duplex Hydraulic Oil Filter SRFA.BH-400×10-Y
Products Description
SRFA series filter is composed of two single-tube filters, reversing valve, bypass valve, signal transmitter, diffuser, etc. It is installed on the top of the oil tank, and the filter element can be replaced without stopping the system. It is suitable for the continuous working hydraulic system oil return filter to filter out the metal powder produced by the wear of various components in the hydraulic system and the rubber impurities of the seal. Etc., to keep the oil flowing back to the oil tank clean to facilitate the circulation of the oil in the system.
|
|
 |
 |
Due to the use of direct return oil filtration in the design, it is very convenient to replace the filter element or add oil to the tank. Simply unscrew the filter cover to replace the filter element or add oil to the tank. Each filter head is equipped with 2 M18 × 1.5 oil ports, and a transmitter can be installed at any location.
The diffuser is installed at the bottom of the oil return cylinder, which can smoothly flow the medium of the oil return into the oil tank, reduce the generation of bubbles, reduce the re-entry of air, and weaken the disturbance of deposited pollutants.
The filter element adopts a new type of synthetic fiber filtration material, which has the advantages of high filtration accuracy, large oil flow capacity, small original pressure loss, and large pollutant holding capacity. Its filtration accuracy is calibrated with * * filtration accuracy, and the filtration ratio β 3, 5, 10, 20>100. The filtration efficiency n ≥ 99%. Compliant with ISO standards.
technical parameter
|
Part number |
Dia (mm) |
Nominal Flow(L/min) |
Filtration rate (μm) |
Nominal Pressure |
Pressure Loss |
Transmitter Device |
Connection |
Weight |
Filter Part No. |
||
|
Initial |
Max |
(V) |
(A) |
||||||||
|
SRFA-25×*L- C/Y |
20 |
25 |
1 |
1.6 |
≤0.08 |
0.35 |
12 |
2.5 |
Thread |
SFAX-25×* |
|
|
SRFA-40×*L- C/Y |
20 |
40 |
SFAX-40×* |
||||||||
|
SRFA-63×*L- C/Y |
32 |
63 |
SFAX-63×* |
||||||||
|
SRFA-100×*L- C/Y |
32 |
100 |
SFAX-100×* |
||||||||
|
SRFA-160×*F- C/Y |
50 |
160 |
Flange |
SFAX-160×* |
|||||||
|
SRFA-250×*F- C/Y |
50 |
250 |
SFAX-250×* |
||||||||
|
SRFA-400×*F- C/Y |
65 |
400 |
SFAX-400×* |
||||||||
|
SRFA-630×*F- C/Y |
90 |
630 |
SFAX-630×* |
||||||||
|
SRFA-800×*F- C/Y |
90 |
800 |
SFAX-800×* |
||||||||
|
Note: * represents the filtration accuracy. If the medium used is water ethylene glycol with transmitter. The filter model is SRFA · BH-63 × * L-Y, and the filter element model is SRFA · BH-63 × *.
|
|||||||||||
